Double-track deck plate-girder viaduct; total length, 398 ft; maximum height, 50 ft; alighment, square. Weight 593 tons. Project Details Owner: Richmond, Fredericksburg & Potomac Railroad Location: Quantico & Richmond, Virginia,…

Consisting of three single-track through plate-girders, respectively 97 ft 0-in, 95 ft 0-in, and 78 ft 0-in long over all. Weight 349.5 tons. Project Details Owner: Bessemer & Lake Erie…

Length 103 ft 0-in c-c. Width of roadway 14 ft. Weight 22.5 tons. Project Details Owner: Fayette and Greene counties Location: Fayette & Westmoreland Counties, Pennsylvania, United States Performed as:…

Consisting of one single-leaf double-track span 150 ft 0-in c-c., and one double-track approach span 64 ft 0-in c-c. Weight 1137 tons Project Details Owner: Chicago & Alton Railway Location:…

Consisting of one single-track through pin-connected span, 387 ft 10-in c-c. Weight 900 tons. Project Details Owner: Pennsylvania Railroad Location: Philadelphia, Pennsylvania, United States Performed as: American Bridge Company Completion…

Consisting of the following single-track through pin spans: One fixed span, 161 ft 3-in c-c.; four fixed spans each 215 ft 0-in c-c.; one fixed span, 235 ft 9-in c-c.;…

Consisting of the following double-track pin-connected deck spans: one fixed span, 192 ft 0-in c-c; eight fixed spans, each 255 ft 0-in c-c; one through lattice draw span, 277 ft…

Consisting of one double-track through pin-connected spn, 174 ft 11.5-in c-c., and 13 double-track deck plate girder spans. Weight 2660 tons. Project Details Owner: New york, New Haven & Hartford…

Consisting of the following double deck through pin-connected spans: One 4-track, 160 ft 0-in c-c; three 4-track, each 156 ft 0-in c-c; One 4-track, 333 ft 0-in c-c; Viaduct at…

Double track. Total length of structure 14,562 ft. Weight 13,161 tons. Project Details Owner: Chesapeake & Ohio Railway Company Location: Richmond, Virginia, United States Performed as: American Bridge Company
