Bridges & Transportation

Single-track deck plate-girder viaduct. Total length, 1,400 ft; alignment, square. Weight 1,500 tons. Project Details Owner: Bessemer & Lake Erie Railroad Location: United States Performed as: American Bridge Company Completion…

Double-track deck plate-girder viaduct. Total length 754 ft 0-in; maximum height, 90 ft; alignment, 2 degree curve; grade, + 1.1492. Weight 1,748.5 tons. Project Details Owner: Cincinnati, New Orleans &…

Work consists of strengthening structure by the introduction of a middle truss in the main spans, and either replacing or reinforcing the spans in the viaduct approaches. Length of main…

Double-track riveted draw span, 277 ft 0-in c-c. In this bridge there are also one 80 ft 0-in and four 100 ft 0-in deck plate-girder spans. Weight 1,500 tons. Project…

Single =track bridge consisting of one pin-connected deck truss span, 200 ft 0-in c-c, and two deck plate-girder spans, each 90 ft 0-in o-o. Weight 384 tons. Project Details Owner:…

Consisting of seven double-track pin-connected spans, each 183 ft 0-in c-c; one double-track deck plate-girder span, 67 ft 0-in c-c; one double-track Scherzer type of bascule span 158 ft 3-in.…

Double-track deck plate-girder viaduct; total length, 422 ft 0-in; maximum height, 68 ft 6-in; alighment, square. Weight 502 tons. Project Details Owner: Southern Railway Location: Sycamore Creek, Virginia, United States…

Single-track deck plate-girder viaduct consisting of 56 spans, each 53 ft 9-in o-o.; alignment, aquare. Weight 574 tons. Project Details Owner: Syracuse Railway Construction Co. Location: Savannah, New York, United…

Channel span only, 396 ft 8-in c-c. Weight 1317.5 tons. Truss Bridge that crosses the Monongahela River. The bridge consists of two parallel spans on a single set of piers.…

Double-track deck plate-girder viaduct; total length 750 ft; maximum height, 57 ft; alighment, square. Weight 890 tons. Project Details Owner: Southern Railway Location: Otter Creek, Virginia, United States Performed as:…
