Bridges & Transportation

Consisting of the following single-track through plate-girders: one each 85 ft 10.25-inch o-o. 112 ft 8-in o-o, 113 ft 6.5-in o-o, and the following double-track spans: one through pin-connected, 498…

Single-track deck plate-girder viaduct. Total length, 755 ft 0-in; maximum height, 91 ft 0-in; alignment, 3 degree curve; grade, + 0.54. Weight 733.5 tons. Project Details Owner: Mill Creek Valley…

Consisting of one through lattice draw span, 380 ft 0-in c-c, and two deck lattice approach spans, each 120 ft 0-in o-o. Double roadway, each 27 ft wide; two walks,…

Two double-track through plate-girder spans, each 126 ft 1-in o-o. Weight 182.5 tons. Project Details Owner: Bessemer & Lake Erie Railroad Location: Butler, Pennsylvania, United States Performed as: American Bridge…

Double-track deck plate-girder viaduct; alignment, square; grade, +1.136; total length, 556 ft 0-in; maximum length 67 ft. Weight 1,079.5 tons. Project Details Owner: Cincinnati, New Orleans & Texas Pacific Railway…

Single-track bridge consisting of two pin-connected deck truss spans, each 175 ft 0-in c-c , and two deck plate-girder spans, each 90 ft 0-in o-o. Weight 505 tons. Project Details…

Consisting of the following single-track spans: three through pin-connected spans, each 400 ft 0-in c-c; one deck riveted latice span, 140 ft 0-in c-c. Weight 2,849 tons. Project Details Owner:…

Consisting of two parallel double-track structures each made up as follows: one through riveted span, 145 ft 0-in c-c; three through pin-connected spans, each 217 ft 0-in c-c; one deck…

Double-track deck plate-girder viaduct. Total length, 650 ft 0-in; alighnemt, square. Weight 489.5 tons. Project Details Owner: Western Alleghenty Railroad Location: Rose Point, Pennsylvania, United States Performed as: American Bridge…

Consisting of the following double-track spans: one through pin-connected, 270 ft 0-in c-c; one deck latice, 143 ft 0-in c-c; eighteen deck plate-girders varing from 10 ft 0-in to 77…
